HEMRC Control Board 2179860-2-H

2179860-2-H
Used
Computed Tomography (CT)
GE Healthcare
GE Healthcare
GE Healthcare
N/A
Outright
Add to Wish List
Sign In & Add To Cart
Sign In & Add To Cart
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Features

  • Standard 9U, 4 layer Board
  • Compliant with UL 478
  • Easy to connect / disconnect
  • Compact size

Product Overview

This HEMRC Control Board is located in the OBC (On Board Controller) chassis which is mounted on the HSA gantry. This board provides interface between OBC and HEMRC. This board is involved in providing three phase motor power to the rotating anode of the X-Ray Tube. The HEMRC control board communicates with the HEMRC through HEMRC interface board (HIF). The board has a push button for manual reset of the board. Three 96 position connectors are provided for the connection of this board with the system. The circuit board is 4 layer board made up of FR-4 Glass fiber, a composite material that consists of glass fabric, and electrical grade epoxy resin. The material is strong and stiff, has a low coefficient of thermal expansion, and outstanding electrical properties. The high quality components are used on the board offer reliable operation and efficient functioning. This board can be used with Lightspeed RT, Lightspeed Pro 16, Lightspeed 16, Lightspeed Ultra, HiSpeed Qxi, Lightspeed Plus, Lightspeed QXi, Discovery ST and Discovery ST (4 Slice, 8 Slice and 16 Slice) systems.

2179860-2-H

  • Additional Features

    • HEMRC (High Efficiency Motor Rotor Controller)

    Compatible Products

    Lightspeed Pro 16

    Lightspeed Pro 16

    Lightspeed RT

    Lightspeed RT

    Lightspeed 16

    Lightspeed 16

    Lightspeed Plus

    Lightspeed Plus

    Lightspeed QXi

    Lightspeed QXi

    Discovery ST

    Discovery ST

    Lightspeed Ultra

    Lightspeed Ultra

    HiSpeed Qxi

    HiSpeed Qxi

    Discovery ST (4 Slice)

    Discovery ST (4 Slice)

    Discovery ST (8 Slice)

    Discovery ST (8 Slice)

    Discovery ST (16 Slice)

    Discovery ST (16 Slice)
